Kinghelm FFC/FPC Connector KH-FG1.0-H2.0-12PIN：A High-quality Solution for Providing Reliable Connections to Electronic Products

PublishTime： 2023-07-13 Article Source：Keysight News Author：SHENZHEN KINGHELM ELECTRONIC CO., LTD

The KH-FG1.0-H2.0-12PIN is a high-quality wire-to-board connector that belongs to the FFC/FPC Connector category. It is designed for a 1mm pitch and features 12 contacts and a flip-locking mechanism. This connector offers various superior characteristics and finds wide applications.

KH-FG1.0-H2.0-12PIN product

Technical Specifications:

1.Temperature Range:-25℃~85℃

2.Rated Voltage: 50V,AC/DC(Equivalent)

3.Contact Resistance: ≤0.03Ω

4.Insulation Resistance:≥500MΩ

5.Pitch:1mm

The KH-FG1.0-H2.0-12PIN wire-to-board/wire-to-wire connector is widely used in various industries. It is commonly found in the manufacturing of electronic products such as smartphones, digital cameras, laptops, and tablets, providing reliable connections for these devices. This connector is essential in applications that require high-density connections or have higher demands for connection reliability. Additionally, it can be used for interconnecting PCB circuit boards with external signals or power sources, facilitating system expansion.

KH-FG1.0-H2.0-12PIN specification
