Hosiden‘s World-first Automotive SoC Type Low Energy Module HRM3012 Acquired Bluetooth Version 5.1 Certification

PublishTime： 2024-02-21 Article Source：HOSIDEN News

Automotive SoC Type Bluetooth® Low Energy Module,SoC type Bluetooth LE module,Automotive Bluetooth® Low Energy module,HRM3012

HOSIDEN has developed the world's first SoC type Bluetooth LE module, HRM3012, for automotive applications. This SoC (System on Chip) employs the CC2642R-Q1 manufactured by Texas Instruments, which enables the embedding of various applications without the need for a host CPU. The unit features a 48MHz ARM® Cortex®-M4F processor and 352KB of flash ROM. All the electrical parts mounted, including SoC, have acquired certification from AEC (Automotive Electronics Council), and the module is subject to the development/manufacturing process control compliant with IATF16949, which is the global quality management system standard for the automotive industry. Such high product quality, along with its wide operating temperature range of -40 to +105℃, has allowed the product to enter a versatile scene of automotive applications. The module incorporates a high-performance pattern antenna backed by technological expertise in consumer products of more than 20 years, ensuring stable communication quality from its compact body. This product has acquired Bluetooth Version 5.1 certification and also supports the long-range and 2M modes introduced in Bluetooth 5.0. The product has also acquired radio communication certifications from Japan and Canada. The module utilizes an edge-face through-hole format, enabling simple checking of the soldering after mounting to the main board.

More and more Bluetooth LE devices will be installed in vehicles in the future and will include such capabilities as linking to smartphones, Smart Key, and fault diagnosis, or will supplant cables for in-vehicle communications. In launching Bluetooth LE products in automotive markets, we are confidently introducing our HRM3012 as an optimum module that will realize your timely and smooth marketing and release, with features such as reduced development load with high-performance antennas, assured manufacturing quality from the edge-face through-hole format, and recognized radio frequency certification.

Model Name and Number

Automotive Bluetooth® Low Energy module: HRM3012

Typical Features

High reliability of AEC-certified components, IATF16949 complaint process

Stable communication using high-performance antenna

Wide operating temperature range of -40 to +105℃

High-performance CPU with low power consumption

Applications

Smart Keys

Fault diagnostic tool

Bluetooth LE communication with Smartphones

Automotive SoC Type Bluetooth® Low Energy Module Specifications
