CSNP4GCR01-AMW
■ Overview
▲ CSNP4GCR01-AMW is an 4Gb density of embedded storage based on NAND Flash and SD controller. This product has many advantages comparing to raw NAND, it has embedded bad block management, and stronger embedded ECC. Even on abnormal power down it still keep your data safely.
▲ CSNP4GCR01-AMW is LGA-8 package. The size is 8mm x 6mm x0.75mm.
■ Features
▲ Interface: Standard SD Specification Version 2.0 with 1-I/O and 4-I/O.
▲ Power supply: Vcc = 2.7V - 3.6V
▲ Default mode: Variable clock rate 0 - 25 MHz, up to 12.5 MB/sec interface speed (using 4 parallel data lines)
▲ High-Speed mode: Variable clock rate 0 - 50 MHz, up to 25 MB/sec interface speed (using 4 parallel data lines)
▲ Operating Temperature: -40°C to +85°C
▲ Storage Temperature: -55°C to +125°C
▲ Standby Current：< 250uA
▲ Switch function command supports High-Speed, eCommerce, and future functions
▲ Correction of memory field errors
▲ Content Protection Mechanism - Complies with highest security of SDMI standard.
▲ Password Protection of SDNAND (CMD42 - LOCK_UNLOCK)
▲ Write Protect feature using mechanical switch
▲ Built-in write protection features (permanent and temporary)
▲ Application specific commands
▲ Comfortable erase mechanism
|
|
|
|
Datasheet |
|
|
|
|
Please see the document for details |
|
|
|
|
|
|
|
|
LGA-8 |
|
|
English Chinese Chinese and English Japanese |
|
|
08/08/2021 |
|
|
V1.3 |
|
|
|
|
|
1.2 MB |
