3PEAK Unveiled Automotive High-Voltage, Low-quiescent Current Voltage Monitor TPV8368Q with High Sense Voltage up to 36V

PublishTime： 2023-04-19 Article Source：3PEAK News

3PEAK, a semiconductor company focusing on the development of high-performance analog chips and embedded processors, has recently unveiled the next-generation automotive high-voltage, low-quiescent current voltage monitor — TPV8368Q. The product, certified by AEC-Q100, meets the operating conditions of automotive chips. In addition, TPV8368Q supports a wide-range input of 36 V. The static power consumption is as low as 2 μA. The monitor voltage and the supply voltage can be separated, while the multi-level monitor reset thresholds and reset delay times are programmable.

Qualified for Automotive Applications
AEC-Q100 Grade 1: TA = −40℃ to 125℃
Supply Voltage Range: 2.4V to 5.5V (SENSE Pin Version)
Wide Supply Voltage Range: 2.4V to 36V (VDD Pin Version)
High Sense Voltage up to 36V for the Sense Pin
Very Low Quiescent Current: 2μA Typical
Fixed Threshold Voltage from 3.0V to 12.0V with 100-mV Step
High Threshold Accuracy ±1.5% Typical
Open-Drain Active Low RESET Output
Green Product, SOT23-6 Package
