UMS Releases New 18GHz Low Noise Amplifier CHA1252-QDG -11, Designed for Space Applications
The CHA1252-QDG is a three-stage Low Noise Amplifier operating in the 11 – 18GHz frequency band. This LNA typically presents low Noise Figure of 1.3dB associated to a small signal gain of 26dB.
It can provide up to 7dBm output power at 1dB gain compression and needs DC power supply of 2V/30mA. It is available in 4×4 plastic package.
Designed for space applications, it is also ideal for a wide range of microwave systems.
This product is developed using a GaAs pHEMT process and is provided on low cost
SMD RoHS compliant QFN plastic package.
