Z51F3220 Product Brief

PublishTime： 2019-11-12 Manufacturer： Zilog Type： Supplier and Product Introduction Language： English

●Overview
■The Z51F3220 MCU, a member of Zilog's new Z8051 product family, is an advanced CMOS 8-bit microcontroller with 32KB of Flash memory. This powerful microcontroller provides a highly flexible and cost-effective solution to many embedded control applications, including battery management, thermostats, and control panels for appliances. With 1KB of RAM, two clocks per machine cycle, general-purpose I/O, multiple timers (1x8-bit, 2x8- bit, 1x16-bit and 2x16-bit), plus PWM, watchdog and watch timers, UART, buzzer port, I²C, on-chip POR, 12-bit ADC and much more, the Z51F3220 MCU is your 32K Flash solution for 8051 embedded application development.
●KEY FEATURES
■High-Performance 8-bit CISC Core
■12 to 16 12-Bit ADC Channels
■LCD Driver (21 segments/8 common)
■Internal RC Oscillator for Lower Component Count
■Timers with Multiple 8- and 16-bit Capture, Counter, Compare and PWM Modes
