L254XF3S 25.4GHz Surface Mount LPF

PublishTime： 2019-10-28 Manufacturer： Knowles Type： Datasheet Language： English

●DESCRIPTION
■DLI introduces its new high frequency surface mountable catalog low pass filters. These LPF's incorporate DLI's high dielectric ceramic materials which provide small size and minimal performance variation over temperature. The catalog LPF's are offered in a variety of frequency bands, which offers a drop in solution for high frequency attenuation.
●FEATURES
■Small Size
■Fully Shielded Component
■Frequency Stable over Temperature
■Solder Surface Mountable
■Excellent Repeatability
■Operating Temp: -55˚C to +125˚C
■Characteristic Impedance: 50Ω
■100% Tested & Inspected
